SN 5800 V
ISODIAMETRIC ARTICULATED NARROW TRACTOR
.png)
.png)
Yanmar Tier3A
Engine
up to 50 hp
4 Cyl 16 Valves
12+12 synchronised gearbox w/ reverser
AGILE AND EFFICIENT
Designed for high-density orchards, vineyards, and nurseries, the SN 5800 V Major is a compact, articulated tractor that offers outstanding manoeuvrability and versatility. With a width of just 98 cm, it easily navigates narrow rows and steep slopes, ensuring precision and efficiency in every task. Its ACTIOTM frame evenly distributes weight across all four driving wheels, maximising grip, stability, and safety. The aggressive design, with wrap-around fenders and smooth lines, enhances its ability to move seamlessly through tight spaces.
-
ACTIOTM Chassis: Full cast-iron frame with a central articulated joint for up to 15° oscillation, maintaining constant traction
-
Articulated Steering: Short wheelbase and hydro guide system for precise handling in tight spaces and on slopes
-
12F+12R synchronised gearbox with reverser
-
Independent dual-clutch (540/1000 rpm)
-
Hydraulic Power Lift: Oscillating lift arms with side stabilisers, 3747 lbs capacity
-
Brakes: Mechanical rear oil-bath disc brakes
-
Steering: Hydraulic power steering with
double-acting pistons -
Safety: Front foldable roll bar
-
Comfort & Control: Analog-digital multifunctional display
Engine
Supercharged diesel with common rail direct injection
Power kW/CV (97/68/CE): 37.9/ 51,5
Emissions Standard: Stage 5
N° Cylinders: 4 - 16 Valves
Rated rpm: 2600
Max torque (Nm/rev): 168,2 Nm/1690
Tank capacity (Iitres): 38.5
Transmission
24 speed synchronised gearbox:
12 FWD + 12 REV with shuttle
Chassis
ACTIOTM integral oscillating frame
Articulated
4 equal-size wheels
Rear final drives
Tyres: 280/70-18 (adjustable rims)
PTO (shaft)
Independent, mechanical control, standard 540 rpm and synchronised
groundspeed 1 3/8” splined
More specs in brochure.
